| Model |
NC-60 |
| Cutting Force |
60 tons |
| Cutting Stroke |
110 mm |
| Open Daylight |
30 – 140 mm |
| Main Motor |
7.5 HP |
| Traverse Speed |
1000 mm/sec. |
| Down Speed |
200 mm/sec. |
| Up Speed |
235 mm/sec. |
| Cutting Head Size |
500 x 500mm or more |
| Machine Bed |
760D x 2300W mm or more |
◎The above are the basic standard specifications. Special specifications are available upon request.
◎Dimensions and weights are for main machine body only without feeder.
◎Open daylight is measured from beam to bed, effective open daylight need to deduct thickness of die, cutting pad and feeder. |
